ASTM A249 Stainless Steel 316L Welded Coiled Tube Exporter, Stainless Steel 1.4436 Coil Tubing, SS UNS S31603 Coiled Tubing, 316L Stainless Steel Coiled Tube Stockist in India
introduction
Dinesh Tube Centre is a leading Stainless Steel 316L Coil Tubing Manufacturer & Supplier in India. One of the highly used grades of Stainless steel is 316L for the manufacturing coil tubings. Grade 316L is the most versatile used SS grade which offers good welding and forming characteristics. This Stainless Steel 316L Coil Tubing is available in lengths up to 2300 feet which is up to 30% longer than traditional offerings. SS tube straighteners make stainless steel coiled tubing installation faster and easier. According to the different applications the SS 316L Coil Tubes are available in different sizes. While fabricating the raw material, we at Dinesh Tube Centre use the finest and good efficient quality of raw material that is used in the manufacturing of coil tubings. The manufacturing is done under the strict provision of trained professionals
Enquire NowSS 316L COILED TUBES SPECIFICATION
Specification : |
||
Outer Diameter | : | 1/16” through 3/4″ |
Thickness | : | 010″ through .083” |
Seamless | : | ASTM A213 and ASTM A269 |
Welded | : | ASTM A249 and ASTM A269 |
Equivalent Grade of Stainless Steel 316L Coiled Tubing
STANDARD | UNS | WERKSTOFF NR. | JIS | AFNOR | BS | GOST | EN |
SS 316L | S31603 | 1.4404 / 1.4436 | SUS 316L | Z7CND17‐11‐02 | 316LS31 / 316LS33 | – | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
Chemical Composition of SS 316L Coiled Tubing
SS | 316L |
Ni | 10 – 14 |
N | 0.10 max |
Cr | 16 – 18 |
C | 0.08 max |
Si | 0.75 max |
Mn | 2 max |
P | 0.045 max |
S | 0.030 max |
Mo | 2.00 – 3.00 |
Mechanical Properties of SS 316L Coiled Tubing
Grade | 316L |
Tensile Strength (MPa) min | 515 |
Yield Strength 0.2% Proof (MPa) min | 205 |
Elongation (% in 50mm) min | 40 |
Hardness | |
Rockwell B (HR B) max | 95 |
Brinell (HB) max | 217 |
Types Of Stainless Steel 316L Coiled Tubing
- Stainless 316L Coiled Tubes
- SS 316L Coiled Tubing
- 316L SS Coiled Tubes
- SS 316L Coiled Tubes Supplier
- SS UNS S31603 Coil Tubing
- SUS 316L Coil Tubing
- 316L Welded Coil Tubing
- ASTM A249 S31603 Coiled Tube
- AISI 316L Coiled Tubing
- SS 316L Seamless Coil Tubing
- DIN 1.4404 SS Coiled Tubing
- 316L Stainless Steel Welded Coil Tubing
- 316L SS Coiled Tubes Price
- ASME SA249 SS 316L Coil Tubing
